Safety Glass for Railings

Safety Glass for Railings is a type of safety glass used for glass railings, balcony railings, stair railings and platform protection systems. The product is usually composed of two or more pieces of tempered glass and an interlayer material in between. Through high-temperature and high-pressure processes, the glass and the interlayer form a stable whole.

Heat-treated glass substrate

After physical or chemical tempering treatment, handrail safety glass forms a high-pressure stress layer on its surface, making its strength 4 to 5 times that of ordinary glass. It has good resistance to bending and impact (such as human impact). When crushed, it breaks down into obtuse small particles (reducing the risk of cuts).

Sandwich structure

Two or more layers of heat-treated glass are bonded together by high-strength PVB (polyvinyl acetal) or SGP (ionic intermediate layer).

The thickness of the middle layer is usually above 1.52mm, and it needs to be thicker for high-rise buildings or areas with high foot traffic (such as 2.28mm).The transparent design enhances the aesthetic appeal of the space.

Good weather resistance

Safety glass for handrails are suitable for different environmental conditions and can with stand the influence of external factors such as sunlight, rain and temperature changes for a long time. By choosing the appropriate glass configuration and intermediate film type, the product can meet the long-term usage requirements in coastal, high-temperature or cold regions.

5mm Tempered + 0.76mm PVB + 5mm Tempered

That is: 5mm tempered glass + 0.76mm PVB interlayer film + 5mm tempered glass

For projects that require higher structural performance, the following can be considered

6mm Tempered + 1.14mm PVB + 6mm Tempered

If the railing adopts a larger glass size, fewer support points or a frameless structure, the SGP sandwich solution can also be considered, for example: 6mm Tempered + 1.52mm SGP + 6mm Tempered

Balcony railing

Residential, apartment, hotel and commercial buildings.

Staircase handrail

It can be matched with stainless steel, aluminum alloy or wooden handrails.

Terrace guardrail

Suitable for residential, hotel and commercial Spaces.

Platform guardrail

It is used for high-rise platforms, public buildings and commercial Spaces.

The railing of the atrium in the shopping mall

Suitable for large-area transparent railing design.

Office building railing

It can be used on stairs, public areas and indoor platforms.

The usual process is:

Original piece inspection → fixed-length cutting → edge grinding → drilling/slotting → tempering → cleaning → interlayer assembly → autoclave treatment → finished product inspection → packaging

Among them, drilling, notching and other processing usually need to be completed before tempering.

Glass size

Ensure that the product matches the railing system.

Tempering quality

Check whether the glass meets the corresponding tempering requirements.

Edge quality

Avoid obvious problems such as chipped edges and cracks that may affect installation.

Hole position accuracy

Ensure that the glass can be accurately connected to the glass clips, columns and point hardware.

"Interlayer state"

Check whether there are obvious abnormalities such as bubbles, impurities, and delamination in the interlayer.

Package

1. Unique designed strong wooden cases.
2. Top Classic Loading Team.
3. Iron/Plastic belt for consolidation.

Q1: Why is safety glass recommended for railings?

A:Railings have a protective function for personnel. Tempered glass can offer better mechanical strength, and the laminated structure can retain the fragments through the interlayer film after the glass breaks, thereby reducing the risk of direct scattering of glass fragments.

Q2: What is the commonly used thickness of safety glass for railings?

A:Common structures include 10.76mm, 12.38mm, 13.14mm, etc., but there is no uniform thickness applicable to all projects. The actual specifications need to be determined based on the size of the glass, the support method, the height of the railing and the design load.

Q3: Which is more suitable for glass railings, PVB or SGP?

A:For regular residential and indoor railings, PVB can be selected according to the project requirements. For large-sized, frameless or railings with high requirements for glass rigidity, SGP can be considered. Ultimately, it should be determined based on the structural design.

If you are looking for safety glass for balconies, staircases, terraces, platforms or railing systems in commercial buildings, we welcome you to provide us with the glass size, installation method, hardware drawings, project location and purchase quantity.

We can assist in selecting the thickness of the glass, PVB/SGP interlayer, interlayer thickness, edge processing and drilling solutions based on the actual railing structure, and provide customized products suitable for engineering procurement.

Contact us for technical solutions, specification confirmation and project quotations of tempered laminated glass for railings.
